Detection Engine¶

The detection engine (guard_core.detection_engine) provides multi-layered threat detection with four components working together: pattern compilation, content preprocessing, semantic analysis, and performance monitoring.

These components are orchestrated by the SusPatternsManager handler, which adapter developers do not call directly but may need to understand for tuning and diagnostics.

Architecture¶

flowchart TD
    DETECT["SusPatternsManager.detect()"]
    PREPROCESS["1. Preprocess content"]
    NORM["Normalize unicode"]
    DECODE["Decode URL + HTML"]
    NULL["Remove null bytes"]
    WHITESPACE["Normalize whitespace"]
    TRUNCATE["Truncate safely"]
    REGEX["2. Regex matching"]
    KIND{"Built-in or custom pattern?"}
    DIRECT["pattern.search() directly, no timeout wrapper"]
    SAFE["Safe matcher: shared thread pool + timeout"]
    PERF["Record performance metrics"]
    SEMANTIC["3. Semantic analysis"]
    PROB["Attack probability scoring"]
    OBFUSC["Obfuscation detection"]
    INJECT["Code injection risk"]
    AGG["4. Aggregate results"]

    DETECT --> PREPROCESS
    PREPROCESS --> NORM --> DECODE --> NULL --> WHITESPACE --> TRUNCATE
    TRUNCATE --> REGEX
    REGEX --> KIND
    KIND -- Built-in --> DIRECT --> PERF
    KIND -- Custom --> SAFE --> PERF
    PERF --> SEMANTIC
    SEMANTIC --> PROB --> OBFUSC --> INJECT
    INJECT --> AGG

Built-in (compile-time-vetted) patterns match directly via pattern.search(), with no per-match thread or timeout. Only custom patterns (added via add_pattern(..., custom=True)) are routed through the safe-matcher timeout wrapper — a custom-pattern match is flagged as timed out once elapsed time reaches 0.9 * compiler.default_timeout (i.e. 0.9 * detection_compiler_timeout when a SecurityConfig is wired; legacy/no-compiler mode falls back to a hardcoded 2.0s field default).

When no SecurityConfig is wired at construction (legacy mode), SusPatternsManager builds neither a PatternCompiler nor a ContentPreprocessor; content is instead truncated to detection_max_content_length (default 10000) via direct slicing before matching, and every pattern — including what would otherwise be a "custom" pattern — runs through the same shared-executor timeout path described above (_check_pattern_with_timeout), reporting to the same success/timeout counters.

PatternCompiler¶

Manages regex pattern compilation with LRU caching and ReDoS safety validation.

Constructor¶

PatternCompiler(default_timeout: float = 5.0, max_cache_size: int = 1000)

Parameter	Description	Bounds
`default_timeout`	Timeout for safe matchers in seconds	N/A
`max_cache_size`	Maximum compiled patterns to cache	Capped at 5000

Key Methods¶

compile_pattern(pattern, flags) -> re.Pattern (async)

Thread-safe compilation with LRU eviction. Cache key is f"{pattern}:{flags}".

compile_pattern_sync(pattern, flags) -> re.Pattern

Synchronous compilation without caching. Used internally by validators and safe matchers.

validate_pattern_safety(pattern, test_strings) -> tuple[bool, str]

Validates a pattern against ReDoS vulnerability:

Checks for known dangerous constructs: (.*)+, (.+)+, nested quantifiers.
Runs the pattern against test strings (default: varying lengths of 'a', 'x'+'y', '<'+'>') on a dedicated single-worker validation_regex_executor() — isolated from the shared shared_regex_executor() scan pool used for live request matching, so a busy scan pool can no longer starve or falsely fail a validation probe.
Elapsed time is measured inside the submitted callable, i.e. execution time only, not time spent queued behind other probes. The outer future.result(timeout=1.0) call bounds total wait to 1.0s, but the pattern is flagged unsafe as soon as a probe's own execution exceeds the stricter 50ms threshold.
Any timeout (queue-bound or per-probe), exception, or a probe over 50ms rejects the pattern — validation is fail-closed.

SusPatternsManager.add_pattern (the async API used by Redis custom-pattern restore and dynamic-rule pattern pushes) runs this validation via asyncio.to_thread, so up to ~1s of ReDoS probing never blocks the event loop. The sync API's add_pattern calls validate_pattern_safety directly on the calling thread.

create_safe_matcher(pattern, timeout) -> Callable[[str], Match | None]

Returns a closure that submits the regex to the shared shared_regex_executor() thread pool (max_workers=4) with a timeout. If the match exceeds the timeout, the future is cancelled and None is returned.

safe_match = compiler.create_safe_matcher(r"<script.*?>", timeout=2.0)
result = safe_match(user_input)  # None if timed out

Every safe_match call — and the legacy no-compiler _check_pattern_with_timeout path — reports its outcome to module-level success/timeout counters. Four consecutive timed-out submissions replace the shared pool with a fresh one: the stale pool is shut down non-blocking (shutdown(wait=False)) and a warning is logged naming the leaked-worker count, so one pathological custom pattern can no longer wedge every worker permanently. Any successful match resets the counter to zero.

batch_compile(patterns, validate) -> dict[str, re.Pattern] (async)

Compiles multiple patterns, optionally validating each for safety. Unsafe or invalid patterns are silently skipped.

ContentPreprocessor¶

Normalizes and sanitizes input before pattern matching.

Constructor¶

ContentPreprocessor(
    max_content_length: int = 10000,
    preserve_attack_patterns: bool = True,
    agent_handler: Any = None,
    correlation_id: str | None = None,
)

Preprocessing Pipeline¶

The preprocess() method runs five stages in order:

Stage	Method	Purpose
Unicode normalization	`normalize_unicode()`	NFKC normalization + lookalike character replacement
Encoding detection	`decode_common_encodings()`	URL decode + HTML entity decode (up to 3 iterations)
Null byte removal	`remove_null_bytes()`	Strips `\x00` and control characters except tab/newline/CR
Whitespace normalization	`remove_excessive_whitespace()`	Collapses multiple spaces, strips leading/trailing
Safe truncation	`truncate_safely()`	Truncates to `max_content_length` preserving attack regions

Attack-Preserving Truncation¶

When content exceeds max_content_length and preserve_attack_patterns is True:

extract_attack_regions() scans for 21 attack indicator patterns (e.g., <script, SELECT ... FROM, eval(, ../).
Regions around matches (100 characters of context on each side) are extracted.
Overlapping regions are merged.
Attack regions are included first, then non-attack content fills remaining space.

This ensures that truncated content still contains the attack patterns for detection.

Unicode Lookalike Map¶

The preprocessor replaces over 20 Unicode characters used for evasion:

Unicode	Replacement	Purpose
`\u2044`	`/`	Fraction slash evasion
`\uff0f`	`/`	Fullwidth solidus
`\u200b`	(empty)	Zero-width space
`\uff1c`	`<`	Fullwidth less-than
`\uff1e`	`>`	Fullwidth greater-than
`\u037e`	`;`	Greek question mark

SemanticAnalyzer¶

Performs structural and statistical analysis of content to detect attacks that evade pattern matching.

Attack Probability Analysis¶

def analyze_attack_probability(self, content: str) -> dict[str, float]

Returns a dictionary mapping attack types to probability scores (0.0 - 1.0):

Attack Type	Keywords Checked	Structural Boost
`xss`	script, javascript, onerror, onload, alert, eval, document...	`<...>` tags
`sql`	select, union, insert, update, delete, drop, from, where...	SQL keywords
`command`	exec, system, shell, cmd, bash, wget, curl, sudo...	`;&\|` operators
`path`	etc, passwd, shadow, hosts, proc, boot, win, ini	`../` traversal
`template`	render, template, jinja, mustache, handlebars...	N/A

The score is computed as: min(keyword_match_ratio + structural_boost, 1.0).

Entropy Calculation¶

def calculate_entropy(self, content: str) -> float

Shannon entropy of the character distribution. High entropy (> 4.5) indicates potential obfuscation or encoded payloads.

Obfuscation Detection¶

detect_obfuscation() returns True when any of:

Entropy > 4.5
More than 2 encoding layers detected
Special character ratio > 40%
Contiguous non-space run > 100 characters

Code Injection Risk¶

analyze_code_injection_risk() scores (0.0 - 1.0) based on:

Code-like patterns ({}, function calls, variable references)
AST parseability (attempts ast.parse(content, mode="eval") with 100ms timeout)
Injection keywords (eval, exec, compile, __import__, globals, locals)

Threat Score¶

def get_threat_score(self, analysis_results: dict) -> float

Aggregates all analysis results into a single 0.0 - 1.0 score:

Component	Weight
Max attack probability	30%
Obfuscation detected	20%
Encoding layers	10-20% (min of layers *10%, 20%)
Code injection risk	20%
Suspicious patterns	5-10% (min of count* 5%, 10%)

PerformanceMonitor¶

Tracks pattern execution performance and detects anomalies.

Constructor¶

PerformanceMonitor(
    anomaly_threshold: float = 3.0,
    slow_pattern_threshold: float = 0.1,
    history_size: int = 1000,
    max_tracked_patterns: int = 1000,
    anomaly_emission_cooldown: float = 60.0,
)

Parameter	Description	Bounds
`anomaly_threshold`	Z-score threshold for statistical anomalies	1.0 - 10.0
`slow_pattern_threshold`	Seconds to consider a pattern slow	0.01 - 10.0
`history_size`	Recent metrics to retain	100 - 10,000
`max_tracked_patterns`	Maximum unique patterns to track	100 - 5,000
`anomaly_emission_cooldown`	Seconds a pattern must wait before it can emit another anomaly event	1.0 - 3,600.0

Metric Recording¶

Each pattern execution records a PerformanceMetric dataclass:

@dataclass
class PerformanceMetric:
    pattern: str
    execution_time: float
    content_length: int
    timestamp: datetime
    matched: bool
    timeout: bool = False

Anomaly Detection¶

Three types of anomalies are detected after each metric recording:

Anomaly Type	Condition
`timeout`	The pattern execution timed out
`slow_execution`	Execution time > `slow_pattern_threshold` (without timeout)
`statistical_anomaly`	Z-score of execution time > `anomaly_threshold` (needs >= 10 samples)

statistical_anomaly only trips when the execution is slower than its pattern's rolling average; a faster-than-usual run is never reported.

Detected anomalies are forwarded to every registered callback on every trip. Sending the anomaly as an event to the agent handler is rate-limited per pattern by anomaly_emission_cooldown: once a pattern has emitted an event, it will not emit another until the cooldown elapses, so a host-wide stall (GC pause, cron job, CPU contention) that makes every tracked pattern trip at once produces one event per pattern instead of a burst. A pattern that is genuinely and consistently slow still reports, just at most once per cooldown window.

Diagnostics¶

Method	Returns
`get_pattern_report(p)`	Stats for a specific pattern (executions, matches, timeouts, avg/max/min time)
`get_slow_patterns(n)`	Top N slowest patterns by average execution time
`get_problematic_patterns()`	Patterns with >10% timeout rate or consistently slow execution
`get_summary_stats()`	Overall summary (total executions, avg time, timeout rate, match rate)

Callback Registration¶

monitor.register_anomaly_callback(lambda anomaly: print(anomaly))

Callbacks receive a sanitized anomaly dictionary with truncated pattern strings.
