SecurityConfig Reference¶

SecurityConfig is a Pydantic BaseModel that controls all guard-core behavior. Adapter developers should expose relevant fields to their users while keeping internal fields (agent, dynamic rules) as implementation details.

Core Settings¶

Field	Type	Default	Description
`passive_mode`	`bool`	`False`	Log-only mode. Logs and emits events but never blocks.
`exclude_paths`	`list[str]`	See below	Paths excluded from all security checks.
`custom_error_responses`	`dict[int, str]`	`{}`	Override error messages for specific HTTP status codes.
`enforce_https`	`bool`	`False`	Redirect HTTP requests to HTTPS globally.
`custom_request_check`	`Callable \\| None`	`None`	Global async function for custom request validation.
`custom_response_modifier`	`Callable \\| None`	`None`	Global async function to modify responses.
`route_resolution_strict`	`bool`	`False`	Block with `500` when the adapter reports it could not resolve the route, instead of running the pipeline with no per-route config. Also turns requests to paths the app does not serve into `500`s rather than `404`s. See Reporting a Failed Match.
`on_error`	`Callable[[str, BaseException, dict], None] \\| None`	`None`	Best-effort callback invoked when a middleware/agent step fails, receiving `(stage, exception, context)`. `stage` is one of `agent_init`, `geoip`, `transport_send`, `encryption`. Also forwarded to `AgentConfig.on_error` when the agent is enabled; see Agent / Telemetry.

Default exclude_paths: ["/docs", "/redoc", "/openapi.json", "/openapi.yaml", "/favicon.ico", "/static"]

Adapter Exposure

All core settings should be exposed to end users. passive_mode is particularly useful for deployment rollouts.

Proxy Configuration¶

Field	Type	Default	Description
`trusted_proxies`	`list[str]`	`[]`	Trusted proxy IPs or CIDR ranges for X-Forwarded-For.
`trusted_proxy_depth`	`int`	`1`	Number of proxies in the X-Forwarded-For chain.
`trust_x_forwarded_proto`	`bool`	`False`	Trust X-Forwarded-Proto header for HTTPS detection.

Validators:

trusted_proxies: Each entry is validated as a valid IP address or CIDR range.
trusted_proxy_depth: Must be >= 1.

Your app server must not pre-resolve the client itself

Leaving trusted_proxies unset only means "X-Forwarded-For is never trusted" if your ASGI/WSGI server isn't already applying that header before guard-core runs. uvicorn's default proxy_headers=True (and equivalent settings in Gunicorn/Hypercorn) does exactly that. See Deployment Prerequisite for the fix.

IP Management¶

Field	Type	Default	Description
`whitelist`	`list[str] \\| None`	`None`	Allowed IPs/CIDRs. `None` disables (allow all).
`blacklist`	`list[str]`	`[]`	Blocked IPs/CIDRs.
`whitelist_countries`	`list[str]`	`[]`	Allowed countries. Non-empty = only listed pass (unknown blocked). Overrides `blocked_countries`.
`blocked_countries`	`list[str]`	`[]`	Country codes always blocked.
`blocked_user_agents`	`list[str]`	`[]`	Regex patterns for blocked user agents.
`enable_ip_banning`	`bool`	`True`	Enable automatic IP banning.
`auto_ban_threshold`	`int`	`10`	Suspicious requests before auto-ban.
`auto_ban_duration`	`int`	`3600`	Ban duration in seconds.

Validators:

whitelist and blacklist: Each entry validated as a valid IP or CIDR range via ipaddress.ip_address() / ip_network().

Whitelist Semantics

whitelist=None means "no whitelist" (all IPs pass). whitelist=[] means "empty whitelist" (no IPs pass). Adapter developers should document this distinction.

Per-Category Bans¶

threat_ban_config lets each detection category carry its own threshold and duration. The pipeline tracks per-category counts in suspicious_request_counts, then walks the matched categories of the current detection. The first category whose own count reaches its threshold triggers a category-tagged ban; if no per-category entry matches, the flat auto_ban_threshold / auto_ban_duration fallback fires off the total count instead.

Field	Type	Default	Description
`threat_ban_config`	`dict[str, ThreatBanConfig]`	`{}`	Per-category ban policy. Validator rejects unknown keys.

When to use:

You want SQL injection detections to be a single-strike ban for a week, but XSS detections to be a 3-strike ban for an hour.
You want to keep the existing flat threshold for any category you do not name.
You want the audit log reasons to disambiguate which category triggered the ban ("penetration_attempt:sqli" vs the flat "penetration_attempt").

from guard_core.models import SecurityConfig, ThreatBanConfig

config = SecurityConfig(
    auto_ban_threshold=10,
    auto_ban_duration=3600,
    threat_ban_config={
        "sqli": ThreatBanConfig(threshold=1, duration=604800),
        "xss": ThreatBanConfig(threshold=3, duration=86400),
    },
)

See Ban Configuration for the ThreatBanConfig model and the full fall-through rule.

Global Behavior Rules¶

global_behavior_rules applies behavior rules to every route without requiring decorators. The merged rules are run alongside any decorator-specified rules. The most common use is service-wide 404-noise correlation, but the same shape supports usage, frequency, and return_pattern rules.

Field	Type	Default	Description
`global_behavior_rules`	`list[BehaviorRuleConfig]`	`[]`	Behavior rules merged into every route.

When to use:

You want a global "ban after 20 404s in 5 minutes" rule that does not require touching every route.
You want detection-correlated thresholds — correlate_with_detection=True halves the threshold (floor 1) when the IP has any positive suspicious_request_counts entry, so probing that already triggered a regex hit gets banned faster.
You want a service-wide frequency or usage cap for any caller, regardless of which route they hit.

from guard_core.models import BehaviorRuleConfig, SecurityConfig

config = SecurityConfig(
    global_behavior_rules=[
        BehaviorRuleConfig(
            rule_type="return_pattern",
            threshold=20,
            window=300,
            pattern="status:404",
            action="ban",
            ban_duration=3600,
            correlate_with_detection=True,
        ),
    ],
)

See Behavior Rules for the full field reference.

Detection Exclusions¶

These fields opt request components out of penetration detection. The header set is merged with a hardcoded default that already excludes host, user-agent, accept, accept-encoding, connection, origin, referer, all sec-fetch-*, and all sec-ch-ua* headers. enabled_detection_categories narrows the regex scan to a subset of the 18 known categories; custom user patterns always run regardless.

Field	Type	Default	Description
`excluded_detection_headers`	`set[str]`	`set()`	Header names skipped by detection. Merged with the hardcoded default list.
`excluded_detection_params`	`set[str]`	`set()`	Query parameter names skipped by detection.
`excluded_detection_body_fields`	`set[str]`	`set()`	Top-level JSON body keys skipped by detection.
`enabled_detection_categories`	`set[str]`	full `ALL_DETECTION_CATEGORIES`	Categories scanned for. Validator rejects unknown labels.

When to use:

A first-party endpoint accepts JSON containing literals (Markdown source, code blobs, URL-shaped query params) that look like attacks but are not.
A regression in one category's regex is producing false positives faster than you can write a fix — disable the category temporarily.
A privacy-sensitive header value should not be scanned at all.
You want different routes to have different opt-outs — pair this with @security.detection_exclusion(...) on the route.

from guard_core.models import SecurityConfig

config = SecurityConfig(
    excluded_detection_params={"q", "search", "filter"},
    excluded_detection_body_fields={"description", "markdown"},
    enabled_detection_categories={"sqli", "xss", "cmd_injection", "ssrf"},
)

IP Lifecycle Controls¶

These fields tune cold-start and horizontal-scale behaviour for the geo-IP and cloud-IP subsystems. They are inert by default — only adjust if you have a specific cold-start or scale-out problem.

Field	Type	Default	Description
`lazy_init`	`bool`	`True`	When `True` (default), run the IPInfo MMDB download and cloud-IP provider fetches as a background task during startup instead of awaiting them inline, so app boot never blocks on multi-second network calls. Cloud and geo layers are inert until the task completes. Set to `False` to await them inline for synchronous-init guarantees.
`geo_ip_db_max_age`	`int`	`86400`	Maximum age in seconds for the IPInfo MMDB before re-download. Range 3600 - 604800.
`cloud_ip_store`	`CloudIpStoreProtocol \\| None`	`None`	Pluggable cloud-IP backend. `None` uses the in-memory default; auto-upgraded to Redis when Redis is enabled.

When to use:

lazy_init=True to keep startup non-blocking when IPInfo MMDB or cloud-IP provider fetches are slow. The background warmup runs concurrently with normal request handling; cloud-provider blocking and geo checks become active once the background task finishes. Rate limiting, IP banning, pattern detection, and other layers remain fully active throughout the warmup window. lazy_init only takes effect when Redis is enabled and the adapter calls initialize_redis_handlers() from its own startup hook (for example fastapi-guard's lifespan integration) — see Provider Status below for the accessor that lets a Kubernetes/ALB warmup probe (or any health endpoint) tell when that window has closed.
geo_ip_db_max_age to tighten or loosen the IPInfo refresh cadence — match it to your IPInfo plan's update frequency.
cloud_ip_store to point multiple horizontally-scaled instances at a single pre-populated Redis namespace, skipping per-instance cloud-IP cold starts.

from guard_core.handlers.cloud_ip_stores import RedisCloudIpStore
from guard_core.handlers.redis_handler import RedisManager
from guard_core.models import SecurityConfig

config = SecurityConfig(
    lazy_init=True,
    geo_ip_db_max_age=43200,
)

shared_store = RedisCloudIpStore(RedisManager(config))
config_with_shared_store = SecurityConfig(cloud_ip_store=shared_store)

Provider Status¶

cloud_handler.get_status() (the module-level singleton) and your IPInfoManager instance's get_status() report per-provider readiness, the last successful refresh timestamp, and a cheap entry count. HandlerInitializer is adapter-internal — its get_initialization_status() combines both into one payload, and adapters expose that combined payload as their status surface (fastapi-guard: SecurityMiddleware.get_initialization_status(), or add_status_route(app) → GET /_guard/status).

Cloud-only status, callable anywhere:

from guard_core.handlers.cloud_handler import cloud_handler

cloud_status = cloud_handler.get_status()
# {
#     "AWS": {"ready": True, "last_refreshed": datetime(...), "entries": 3421},
#     "GCP": {"ready": False, "last_refreshed": None, "entries": 0},
#     ...
# }

Geo-IP status — call get_status() on the IPInfoManager instance you passed in as geo_ip_handler (there is no module singleton: the manager is token-gated, so it is instantiated per app, not at import time):

geo_status = ip_info_manager.get_status()
# {"ready": True, "last_refreshed": datetime(...), "entries": 494}

Combined cloud + geo-IP payload, for a warmup probe or health endpoint — read it through your adapter rather than reconstructing HandlerInitializer yourself (fastapi-guard):

from guard.status import add_status_route

add_status_route(app, path="/_guard/status")  # GET /_guard/status -> combined payload
# or, in-process: security_middleware.get_initialization_status()
# {
#     "cloud_providers": { ...as above... },
#     "geo_ip": { ...as above... },
# }

geo_ip is None when no geo_ip_handler is configured. A custom geo_ip_handler that does not implement get_status() still reports ready (from the required is_initialized property) with last_refreshed/entries as placeholders. This is synchronous, dependency-free, and cheap enough to poll from a warmup probe or health endpoint — it is exactly what to wire up for the "cannot tolerate any inert window" case above.

See Cloud IP Store for the protocol contract and the Redis namespace migration note.

Geolocation¶

Field	Type	Default	Description
`geo_ip_handler`	`GeoIPHandler \\| None`	`None`	Custom geolocation handler implementing the protocol.
`ipinfo_token`	`str \\| None`	`None`	Deprecated. IPInfo API token.
`ipinfo_db_path`	`Path \\| None`	`data/ipinfo/country_asn.mmdb`	Deprecated. Path to IPInfo database.

Model validator: If blocked_countries or whitelist_countries are set, geo_ip_handler must be provided (or ipinfo_token for backward compatibility). Raises ValueError otherwise.

Rate Limiting¶

Field	Type	Default	Description
`enable_rate_limiting`	`bool`	`True`	Master switch for rate limiting.
`rate_limit`	`int`	`10`	Maximum requests per window (global).
`rate_limit_window`	`int`	`60`	Window duration in seconds (global).
`endpoint_rate_limits`	`dict[str, tuple[int, int]]`	`{}`	Per-endpoint overrides `{path: (limit, window)}`.

Cloud Provider Blocking¶

Field	Type	Default	Description
`block_cloud_providers`	`set[str] \\| None`	`None`	Providers to block. A bare name (`"AWS"`, `"GCP"`, `"Azure"`) blocks the whole provider; a region carve-out (`"GCP:!us-central1"`) blocks the provider except that region. Region scoping is supported for GCP and AWS.
`cloud_ip_refresh_interval`	`int`	`3600`	Seconds between IP range refreshes (60-86400).

Validator: each entry is kept only if the part before an optional :!region suffix is one of {"AWS", "GCP", "Azure"}; an entry that fails this check is dropped, not the whole set.

Security Headers¶

Field	Type	Default	Description
`security_headers`	`dict[str, Any] \\| None`	See below	Security headers configuration dict.

Default structure:

{
    "enabled": True,
    "hsts": {"max_age": 31536000, "include_subdomains": True, "preload": False},
    "csp": None,
    "frame_options": "SAMEORIGIN",
    "content_type_options": "nosniff",
    "xss_protection": "1; mode=block",
    "referrer_policy": "strict-origin-when-cross-origin",
    "permissions_policy": "geolocation=(), microphone=(), camera=()",
    "custom": None,
}

CORS¶

Field	Type	Default	Description
`enable_cors`	`bool`	`False`	Enable CORS header injection.
`cors_allow_origins`	`list[str]`	`["*"]`	Allowed origins.
`cors_allow_methods`	`list[str]`	`["GET", "POST", ...]`	Allowed HTTP methods.
`cors_allow_headers`	`list[str]`	`["*"]`	Allowed request headers.
`cors_allow_credentials`	`bool`	`False`	Allow credentials in CORS requests.
`cors_expose_headers`	`list[str]`	`[]`	Headers exposed in CORS responses.
`cors_max_age`	`int`	`600`	Preflight cache duration in seconds.

Redis¶

Field	Type	Default	Description
`enable_redis`	`bool`	`True`	Master switch for Redis.
`redis_url`	`str \\| None`	`"redis://localhost:6379"`	Redis connection URL.
`redis_prefix`	`str`	`"guard_core:"`	Key prefix for namespace isolation.
`redis_socket_connect_timeout`	`float \\| None`	`2.0`	Seconds to wait establishing a TCP connection. Must be positive; `None` disables (blocks indefinitely on a partitioned Redis).
`redis_socket_timeout`	`float \\| None`	`2.0`	Seconds to wait on a read/write before raising. Must be positive; `None` means no timeout.
`redis_health_check_interval`	`int`	`30`	Seconds between pooled-connection health checks. `0` disables.
`redis_max_connections`	`int \\| None`	`None`	Cap on the connection pool size. `None` uses redis-py's default.
`redis_retries`	`int`	`1`	Retries (with exponential backoff) on transient connection/timeout errors. `0` disables.
`redis_fail_open`	`bool`	`False`	On Redis outage, `fail_secure` governs by default. Set `True` to skip the failing check and let the request through, treating Redis outages as an availability concern distinct from other check failures.

Detection Engine¶

Field	Type	Default	Range	Description
`enable_penetration_detection`	`bool`	`True`	N/A	Master switch for threat detection.
`detection_compiler_timeout`	`float`	`2.0`	0.1 - 10.0	Timeout for pattern compilation/matching (s).
`detection_max_content_length`	`int`	`10000`	1000 - 100000	Maximum content length for detection.
`detection_preserve_attack_patterns`	`bool`	`True`	N/A	Preserve attack patterns during truncation.
`detection_semantic_threshold`	`float`	`0.7`	0.0 - 1.0	Threshold for semantic attack detection.
`detection_anomaly_threshold`	`float`	`3.0`	1.0 - 10.0	Std deviations slower than average to flag an anomaly (never faster).
`detection_slow_pattern_threshold`	`float`	`0.1`	0.01 - 1.0	Seconds to consider a pattern slow.
`detection_monitor_history_size`	`int`	`1000`	100 - 10000	Recent metrics to keep in history.
`detection_max_tracked_patterns`	`int`	`1000`	100 - 5000	Maximum patterns to track for performance.
`detection_max_body_inspect_bytes`	`int`	`262144`	1024 - 10485760	Body size cap read/scanned for detection; distinct from `detection_max_content_length` and `max_request_size`.
`detection_threat_score_threshold`	`float`	`1.0`	0.0 - 10.0	Anomaly/threat score required to flag a request.
`detection_scan_body`	`bool`	`True`	N/A	Scan the request body during detection; `False` restricts detection to path/query/headers.

Logging¶

Field	Type	Default	Description
`log_suspicious_level`	`"INFO" \\| "DEBUG" \\| "WARNING" \\| "ERROR" \\| "CRITICAL" \\| None`	`"WARNING"`	Log level for suspicious requests. `None` disables.
`log_request_level`	Same as above	`None`	Log level for all requests. `None` disables.
`log_country_check_level`	Same as above (default `"INFO"`)	`"INFO"`	Log level for non-block country verdicts (whitelisted / not-affected). `None` disables. Blocked-country hits log at `log_suspicious_level` instead (default `WARNING`); no-rules / no-geolocation always log at `DEBUG`.
`log_format`	`"text" \\| "json"`	`"text"`	Log output format.
`custom_log_file`	`str \\| None`	`None`	Path to a custom log file.

Agent / Telemetry¶

Internal Configuration

Agent fields are typically not exposed to end users. They are used for Guard Agent SaaS integration.

Field	Type	Default	Description
`enable_agent`	`bool`	`False`	Enable Guard Agent telemetry.
`agent_api_key`	`str \\| None`	`None`	API key for the SaaS platform.
`agent_strict`	`bool`	`False`	Raise at middleware init instead of degrading to agent-off when an enabled agent cannot be initialized.
`agent_endpoint`	`str`	`"https://api.guard-core.com"`	Agent endpoint URL.
`agent_project_id`	`str \\| None`	`None`	Project identifier.
`agent_buffer_size`	`int`	`100`	Events to buffer before flush.
`agent_flush_interval`	`int`	`30`	Seconds between automatic flushes.
`agent_enable_events`	`bool`	`True`	Send security events.
`agent_enable_metrics`	`bool`	`True`	Send performance metrics.
`agent_timeout`	`int`	`30`	HTTP request timeout in seconds.
`agent_retry_attempts`	`int`	`3`	Retry attempts for failed requests.
`agent_project_encryption_key`	`str \\| None`	`None`	Per-project AES-256-GCM key that switches the agent to the encrypted events endpoint. Required for API keys with encryption enforced server-side.
`agent_guard_version`	`str \\| None`	`None`	Framework wrapper version (e.g. fastapi-guard's `__version__`) reported alongside agent telemetry.
`agent_status_interval`	`int`	`300`	Seconds between agent status reports to the SaaS. Must be between 60 and 86400.
`agent_high_watermark_ratio`	`float \\| None`	`None`	Buffer occupancy ratio that triggers an early flush. `None` defers to the agent's own default (`0.8`).
`agent_max_concurrent_flushes`	`int \\| None`	`None`	Maximum concurrent early-flush operations. `None` defers to the agent's own default (`1`).
`agent_buffer_overflow_policy`	`Literal["drop", "block", "raise"] \\| None`	`None`	Behavior when the agent's in-memory buffer is full. `None` defers to the agent's own default (`"drop"`).
`agent_backoff_factor`	`float \\| None`	`None`	Backoff factor for agent HTTP retries. `None` defers to the agent's own default.
`agent_sensitive_headers`	`list[str] \\| None`	`None`	Header names excluded from telemetry payloads. `None` defers to the agent's own default.
`agent_max_payload_size`	`int \\| None`	`None`	Maximum payload size in bytes included in events. `None` defers to the agent's own default.
`agent_compression_enabled`	`bool \\| None`	`None`	Gzip-compress outgoing batch bodies above `agent_compression_threshold`. `None` defers to the agent's own default.
`agent_compression_threshold`	`int \\| None`	`None`	Minimum body size in bytes before gzip compression applies. `None` defers to the agent's own default.
`agent_install_id`	`str \\| None`	`None`	Override the agent install ID. `None` auto-generates one.
`agent_payload_signing_secret`	`str \\| None`	`None`	HMAC-SHA256 secret used to sign the `X-Payload-Signature` header.

Validator: agent_api_key is required when enable_agent is True. agent_buffer_overflow_policy rejects any value other than "drop", "block", or "raise" at construction time.

SecurityConfig.on_error (documented under Core Settings hooks) is also forwarded to AgentConfig.on_error when the agent is enabled, so the same callback receives agent-side transport_send and encryption failures in addition to guard-core's own agent_init and geoip failures.

All eleven fields above with a None default follow the same rule: to_agent_config() omits a field from the AgentConfig call entirely when it is None, so an unset field is controlled by AgentConfig's own default rather than by a value duplicated into guard-core.

Dynamic Rules¶

Field	Type	Default	Description
`enable_dynamic_rules`	`bool`	`False`	Enable dynamic rule updates from SaaS platform.
`dynamic_rule_interval`	`int`	`300`	Seconds between rule update checks.
`emergency_mode`	`bool`	`False`	Emergency lockdown mode (set by dynamic rules).
`emergency_whitelist`	`list[str]`	`[]`	Emergency whitelist IPs (set by dynamic rules).

Validator: enable_agent must be True when enable_dynamic_rules is True.

Validators¶

SecurityConfig includes Pydantic validators that run on instantiation:

Validator	Fields	Behavior
`validate_ip_lists`	`whitelist`, `blacklist`	Validates IP addresses and CIDR ranges. Raises `ValueError` on invalid entries.
`validate_trusted_proxies`	`trusted_proxies`	Validates proxy IPs and CIDR ranges. Raises `ValueError` on invalid entries.
`validate_proxy_depth`	`trusted_proxy_depth`	Must be >= 1. Raises `ValueError` otherwise.
`validate_cloud_providers`	`block_cloud_providers`	Silently filters invalid providers: an entry is kept only if the part before an optional `:!region` suffix is `"AWS"`, `"GCP"`, or `"Azure"`.
`validate_geo_ip_handler_exists`	model-level	Requires `geo_ip_handler` when `blocked_countries` or `whitelist_countries` is set. Falls back to `IPInfoManager` if `ipinfo_token` is provided.
`validate_agent_config`	model-level	Requires `agent_api_key` when `enable_agent` is `True`. Requires `enable_agent` when `enable_dynamic_rules` is `True`.
`validate_optional_extras_installed`	model-level	Requires the `redis` extra when `enable_redis` is `True`, the `cloud` extra (`aiohttp` or `requests`) when cloud blocking is enabled (`block_cloud_providers` or `enable_dynamic_rules`), and the `geo` extra (`maxminddb`) when country rules are configured with no custom `geo_ip_handler`. Raises `ValueError` naming the missing extra's install command, checked via `importlib.util.find_spec` (never a bare `import`). See Installation.
`warn_unknown_fields`	model-level, `mode="before"`	Compares the constructor keyword arguments against `model_fields` (and any field's `alias`) and logs a `guard_core.models` warning naming each unknown key, since `SecurityConfig` still allows unknown keys through (`extra="ignore"`) rather than raising. Construction still succeeds and the unknown key is still dropped; only a log line is added, so a typo'd field name is no longer a silent no-op. `extra="forbid"` is the intended behavior at a future major release.

Silent filtering

validate_cloud_providers silently drops unrecognized provider names. {"AWS", "InvalidProvider"} becomes {"AWS"} without raising an error.
